coczow PM6811

coczow PM6811 ციფრული ტენიანობის მრიცხველის მომხმარებლის სახელმძღვანელო

Model: PM6811 | Brand: coczow

1. შესავალი

The coczow PM6811 Digital Moisture Meter is a professional tool designed for quick and precise measurement of moisture content in various materials, including wood and building materials. Equipped with high-precision pins and an easy-to-read LCD display, this device helps identify hidden water leaks and assess moisture levels to prevent material damage and deformation. Its user-friendly features, such as a multi-color backlight display, data hold, and automatic shut-off, make it an essential tool for woodworking, construction, and home maintenance.

2. უსაფრთხოების ინფორმაცია

3. Package Contents and Device Overview

3.1. პაკეტის შიგთავსი

3.2. მოწყობილობის კომპონენტები

The image below illustrates the main components of the coczow PM6811 Digital Moisture Meter and its accessories.

coczow PM6811 Digital Moisture Meter with accessories including batteries, replacement pins, and wrench.

Figure 1: coczow PM6811 Digital Moisture Meter and Included Accessories

Key components include the main unit with its LCD display, two measurement pins at the top, control buttons on the front panel (HOLD, MAX/MIN, MODE, Power), and a protective cap for the pins.

4. დაყენება

4.1. ბატარეის მონტაჟი

  1. იპოვეთ ბატარეის განყოფილების საფარი მოწყობილობის უკანა მხარეს.
  2. Open the cover by sliding or unscrewing it (if applicable).
  3. ჩადეთ ორი 1.5 ვოლტიანი AAA ბატარეა, დარწმუნდით, რომ სწორი პოლარობაა (+/-).
  4. უსაფრთხოდ დახურეთ ბატარეის განყოფილების საფარი.

4.2. პირველადი ჩართვა

Press the Power button to turn on the device. The LCD display will illuminate, showing the current measurement mode and other indicators.

5. საოპერაციო ინსტრუქციები

5.1. Selecting Material Type (Wood Groups)

The PM6811 offers 6 calibrated scales for different wood types and a setting for building materials. Use the 'MODE' button to cycle through these options:

The device is suitable for various wood types and building materials.

Moisture meter being used on different types of wood to show its versatility.

Figure 2: Measuring Moisture in Various Wood Types

Moisture meter being used on a brick wall, demonstrating its application for building materials.

Figure 3: Measuring Moisture in Building Materials

5.2. გაზომვის ჩატარება

  1. ამოიღეთ დამცავი ქუდი საზომი ქინძისთავებიდან.
  2. Select the appropriate material type using the 'MODE' button.
  3. Gently push the two pins into the surface of the material you wish to measure. Ensure both pins are fully inserted and making good contact.
  4. Read the moisture content percentage ნაჩვენებია LCD ეკრანზე.
  5. Once the measurement is complete, carefully remove the pins and replace the protective cap.
Close-up of the moisture meter's pins inserted into a piece of wood, showing a digital reading.

Figure 4: Taking a Moisture Measurement

5.3. ეკრანის გაგება

The LCD display provides clear readings and visual indicators:

Three moisture meters displaying different backlight colors (green, orange, red) corresponding to low, medium, and high moisture levels.

Figure 5: Multi-Color Backlight Indicating Moisture Levels

5.4. შეკავების ფუნქცია

Press the 'HOLD' button to freeze the current measurement on the display. This is useful for taking readings in hard-to-reach areas. Press 'HOLD' again to release the reading.

5.5. MAX/MIN Measurement

The device can record the maximum and minimum moisture readings during a measurement session. Press the 'MAX/MIN' button to view ამ ღირებულებებს.

5.6. ავტომატური გამორთვა

To conserve battery life, the PM6811 features an automatic shut-off function. If no buttons are pressed for approximately 5 minutes, the device will power off automatically.

6. მოვლა

7. Დიაგნოსტიკა

8. ტექნიკური მახასიათებლები

ფუნქციასპეციფიკაცია
მოდელის ნომერიPM6811
მწარმოებელიCOCZOW
ზომები5 x 3.5 x 13 სმ
ნივთის წონა150 გრამი
დენის ტიპიBattery (2 x 1.5V AAA Alkaline)
Wood Measurement Range2.0% - 75.0%
Building Material Measurement Range1.5% - 30%
ავტომატური გამორთვადაახლ. 5 წუთი უმოქმედობა
ჩვენებაLCD with multi-color backlight

9. გარანტია და მხარდაჭერა

The coczow PM6811 Digital Moisture Meter comes with a standard manufacturer's warranty. For detailed warranty information, technical support, or service inquiries, please refer to the contact information provided on the product packaging or the official coczow webსაიტი. გთხოვთ, შეინახოთ შეძენის დამადასტურებელი საბუთი გარანტიის მოთხოვნისთვის.
